HKS 93-98 Toyota Supra Turbo 1.6mm Stopper Head Gasket 2301-RT042

Special Order

Manufacturer Part Number: 2301-RT042

Quantity

$499.95 CAD

Sale Sold out

Shipping calculated at checkout.

This is a SPECIAL ORDER item, please allow an additional 10-20 days delivery. IF longer ETA or delays we will conatct you. Thank-You.

Shipping: All warehouse products ship to our Hamilton, Ontario location prior to shipping out to you or for in-store pick-up. Ships from our location in 3-5 business days after.

HKS 93-98 Toyota Supra Turbo 1.6mm Stopper Head Gasket is a 1.6mm Stopper Type Metal Head Gasket designed for the Toyota 2JZ-GTE engine (1993-1998 Supra). Engineered for high-boost/high-horsepower applications, this multilayer steel gasket features a molded stopper ring for improved sealing and a compressed thickness of 1.6 mm, designed for a 88mm bore.

Engine Application: Toyota 2JZ-GTE / 2JZ-GE (Supra, Aristo, IS300, SC300/Soarer)
Thickness: 1.6 mm
Bore Diameter: 𝟇88mm
Compression Ratio: ⋴ = 8.21
Type: Stopper Type (High-pressure sealing around combustion chambers)
Material: Multi-layer steel (typically 3-5 layers) coated with special fluorine rubber.
Increased Sealing: The "stopper" design provides superior sealing around the combustion chamber compared to standard bead-type gaskets.
High Performance: Built to withstand extreme temperatures and pressure in modified engines.
Robust Construction: Multiple steel layers allow for better flexibility and sealing even with engine movement.

Note: It is generally recommended to ensure head and block surfaces are properly machined (flat) to maximize the effectiveness of this metal gasket.

MPN: 2301-RT042

SKU:HKS2301-RT042
