Electric Pump Chevy SB High Flow, 55 GPM WP301S NV CLEARANCE

American made with quality far superior to any other performance aftermarket company, we build our water pumps with pride right here in the USA. Don't be mislead by inflated flow numbers and competitors' outlandish claims. Our 300 series pumps move more water and produce more pressure than any other electric pump on the market. That means better protection for your high horsepower, high demand engine! Our 2 year, unlimited mileage guarantee and full satisfaction money back guarantee should convince you that buying Meziere is buying value.

This water pump model features:

• Fits small block Chevrolet
• Suitable for street or drag strip use – 3000+ hour life expectancy
• Show quality finish
• High flow design provides 55 gallons per minute free flow rating
• All stainless steel hardware included
• Light weight. Complete small block Chevy unit weighs only 7.0 pounds!
• Stainless steel large diameter main shaft with high performance ceramic seal
• Pump will clear cam belt drives and most blower drives
• Welded 1 3/4" inlet connection

• Belt Drives: Standard SBC design will clear Jesel belt drives and comparable belt drive systems.
• Distributer Belt Drives: Spacers will be necessary to clear belt drive distributor systems.
• Finishing The System: This pump is supplied complete with gaskets and hardware. No additional items should be necessary for standard installations.
• Amperage draw: Under normal use the pump will draw 11-12 amps.
• Overall Height Dimension: The standard pump is 7.28" long from the mounting surface to the tip of the pump.
• Pump Weight: This application weighs 7.0 lbs.
• 16 volt systems: The 12 volt pump will work for limited use applications. Do not run the pump while charging the 16v system.
• Note for Ported Pumps: Port description is -8AN ORB and will accept any of our WPM fittings.

Additional Notes:

The standard 35 GPM pump is suitable for normally aspirated engines up to 650HP. Supercharged, turbocharged and high compression, high horsepower applications should use the 55GPM High Flow pump only. This model is available in ported and non-ported configuration. The -8AN ORB low pressure port can act as a heater, bypass or expansion tank connection.

MPN: WP301S

Final Sale
